OBD + GPS HUD P24 Car OBD Head Up Display HUD On Board Computer Digital Speedometer With Fuel Consumption Slope meter Auto Electronic Accessories

Auto-match models, plug and play

According to OBD or EUOBD,( the on-board auto-matic diagnosis system) plug and play.

- Judgment method:

Open and find the sticker under the hood.

lf OBD2 CERTIFILE can be installed (as shown in Figure 1)Or check whether there is an automobile diagnosis port under the steering wheel (as shown in figure 2)

(u.s. cars can be used after 2003 and most other cars after 2007.)

Package Included:

1 x Head Up Display

Parameter Settings :

Language Set: Simplified Chinese/ Traditional Chinese/ English/Japanese/Korean/Thai/Russian/Arabic/Malay/Spanish/German/French

Sound Switch: ON=Turn on the alarm, OFF=Turn off the alarm

Speed Alarm: Alarm when the vehicle speed >150, adjust range is 5-200

Coolant Alarm: Alarm when the water temperature >120, adjust range is 50-200

RPM Alarm: Alarm when the engine speed >6000r/min, adjust range is 1000-8000

BAT alarm: Alarm when the voltage <10.5v, the setting range is 10.0-15.0v

Speed Adjust: If the speed is not correct,please change this default value. (e.g. instrument display 100 Km/h HUD shows 105Km/h, set the value to 107-5=102)

Speed Offset: When the vehicle speed does not return to 0 after the car is turned off (E.g. speed display 5Km/h,please adjust HUD to 6Km/h)

BAT Adjust: If voltage is wrong,can change this value (If the hud displays 0.2V higher than the instrument voltage, the device is adjusted to 98%)

Engine Size: When the fuel consumption error is large, adjust according to the displacement (If the car displacement is 3.6L, adjust the parameter value to 3.6L)

Fuel Adjust:If the fuel consumption is not correct, changethis value. (eg. the device displays 0.2L higher than the instrument voltage, adjust the value to 98%)

Brightness：Auto= Automatic light sensitivity, 1= The darkest, 8 =The brightest

RPM = The RGB lights color will change according to the RPM

SPEED= The RGB lights color will change according to the speed

OFF= Turn off the RGB light

BLUE= Blue RGB light

RED= Red RGB light

PURPLE=Purple RGB light

CWT Unit：°C =Celsius °F =Fahrenheit

Product Description:

X90 is a smart GPS multi-functional horizontal speedometer for driving, fully supports high-precision monitoring of car speed,vehicle tilt angle, vehicle pitch angle changes, compass, time and car battery voltage status, to ensure your driving safety.

Feature:

★Applicable to Asian cars, American cars, European cars.

★Equipped with high-precision satellite GPS signal module.

★Automatically monitor vehicle driving conditions.

★Adjust the brightness of the screen by using the sensitivity of the light sensor.

★Free rotation, which is more sensitive.

★It adopts color HD LCD display with high resolution.

Function:

Precisely shows vehicle tilt angle with clear notification, when the angle is over 40°, alarm alerts.

Precisely show vehicle pitch angle changes,when the angle is over 40°the alarm alerts to insure your safety.

After connected to power supply, there will be backlight inside, which will help you see accurately in case of night or dark situation.

Elevation error within 5- 100 meters.

After the vehicle starts the speedometer starts automatically, after car parking the meter will be in sleep mode automatically.

Over speed alarm.

Fatigue driving alarm alerts after driving for 4 hours

Specification:

Power: DC 10V~30V

Depression&Elevation angle: -40℃ +40℃

Clock Error Value: < 1 minute

Voltage measurement accuracy: O.5V

GPS Cold Boot Time: 32s (average)

GPS Data Refresh Time: 1s

Working Temperature: -40℃ ~ +80℃

Roll Angle:-40℃ +40℃

Voltage Measurement Range: DC5V~30V

Speed Accuracy: < 0.36Km/h

GPS Hot Boot Time: 1s (average)

Wireless Transmission Frequency:2.4GHz

Product Size:170*68*60(mm)

Instruction:

Park the car on a level surface, stick the adhesive on the product, adjust and fix it in the vehicle for easy horizontal view.

Before driving, connect the power supply and wait to receive the satellite GPS signal until the data shows normal.

Long and hold the setting button and click the start button to adjust the electronic clock.

Press and hold the start button, and click the setting button to adjust the time of the X90.

Package Included:

1*X90 HUD

1*Cigare lighter

1*Fixed pad

1*Instruction manual

1*Packing box

How To Switch From Miles To Km?

it supports both MPH/h and KM/h

Press M , switch MPH/h inch and KM/h metric

(Note: Altitude is in feet in MPH/h mode and meters in KM/h mode)

(Explanation: MPH/h lights up to MPH/h Mode, MPH/h is off to indicate KM/h mode)

How to adjust the time?

In the state of power off, press the power button. After the screen lights up, press and hold the M button / power button 3-4 seconds immediately

1. Decrease time: Long press the M key will automatically enter the time adjustment interface.

M key (left): adjust the hour hand, power button (on the right): adjust the second hand.

2. Add time: long press the power button.

some country's time is slower /faster than GPS time some hours

You can adjust time according to the user manual

Features:

Real-time measurement of the vehicle roll and pitch angle during driving, the range is -40°~ +40°.

The current altitude of your car can be measured.

GPS satellite positioning, make sure you don't go in the wrong direction. Perfect for traveling and driving adcentures.

Obtain the current driving speed, with over speed alarm function, as well as display the local time.

Real-time
voltage monitoring, can avoid safety hazards caused by too high or too
low voltage, prolonging the lifespan of the battery.

Suitable for all vehicles, such as vans, trucks, buses, cars, off-road cars, SUVs, and other Vehicles.

Specification:

Power supply: DC10V~30V;

Operating temperature: -40°C~+80°C;

Pitch angle: -40°~+40°;

Roll angle: -40°~+40°;

Voltage measurement range: DC10V~30V;

Voltage measurement accuracy: 0.5V;

Speed accuracy: ＜0.36Km/h;

GPS data refresh rate: 1s;

GPS hot start: 1s（AVG）；

Wireless transmission frequency: 2.4GHz;

GPS cold start: 32s（AVG）；

Description:

Name: Head Up Display
Material: ABS+PC
Colour: Black
Light color: green light
Chip: GPS+ Beidou dual-mode chip
Display type: 2.5 inches LCD screen
Input voltage: DC 5V
Universal: Compatible with all cars, trucks and motorcycles

Feature:

1. With compass: With GPS navigation direction compass, it helps the driver by indicating the direction. Equipped with a light sensor, the brightness can be adjusted according to different light conditions, and it is very clear under strong light, providing a safer day and night driving experience.
2. Green eye protection: large font design, easy to read. The green lettering and green light will make the driver more comfortable and protect the driver's eyes, especially suitable for long-distance driving.
3. Simple installation: just install the device near the dashboard, or use the 360-degree rotating suction cup to install the device on the windshield, plug and play, powered by the cigarette lighter USB cable, automatically powered on according to the engine ignition and power off.
4. Applicable to all vehicles: The head-up display is equipped with a GPS+Beidou dual-mode chip, which has a fast refresh rate and no lag. Universal for all vehicles such as cars, trucks, SUVs, motorcycles, golf carts and more.

Details:

--Multi-function speedometer: display speedometer, clock, satellite number, driving direction and other information in your driving field of view.
--You can safely view driving information without having to take your eyes off the front, allowing you to relax and focus on driving maneuvers more safely.
--Abnormal alarm function: Additional instrument with over-speed and fatigue driving alarms to make your driving safer and more comfortable.
--With GPS navigation direction compass

Packing list:

1 x Head Up Display
1 x USB cable
1 x suction cup support
1 x double-sided adhesive tape
1 x Instructions
